Image Intensifier Size
Orbital Movement
Wig-Wag Movement
Vertical Movement
Horizontal Movement
Depth
Free Space
SID
Rotation
9″ | 12″
135 Degrees (45 Degrees Overcast)
/- 12.5 Degrees
19.69″ In
7.87″ In
28.35″ In | 28.74″ In
30.94″ In | 31.02″ In
39.37″ In (100 cm)
/- 190 Degrees
Inverter Frequency
Power
kV Range On Fluoroscopy
mA Range On Fluoroscopy
kV Range On Radiography
Max Value Of Radiography Current
mAs
Snap Shot
40 kHz
15 kW
40-120 kV
0.1-7 mA / 10-45 mA
40-120 kV
70 mA
0.4-100 mAs
10-25 mA
Anode Heat Capacity (HU)
Small Focus
Large Focus
Anode Type
Collimation
300,000 HU
0.3 mm
0.6 mm
Rotating
Iris & Blades
I.I.
Camera Type
Image Capacity
LIH, Digital Recording
Edge Enhancement
Pulse Mode
A/D Conversion
Frames Per Sec
CINE Loop Recording
Monitor
Dual Monitor Display
Digital Memory Image Processing
9/6/4.5″ or 12/9/6″
CCD Camera (1k x 1k Pixel Resolution)
100,000
YES
YES
Pulse Mode & Minimum Does Mode
14 Bit
45 / 30 / 15 / 5 fps
YES (up to 30 fps)
19″ Flat Panel LCD (B&W / Medical Grade)
YES
ZENIS System / Windows
Laser Pointer
DICOM 3.0
USB Storage
Thermal Printer
Manufacture Warranty
YES (Optional)
YES (Standard)
YES (Standard)
YES (Optional)
2 Years Parts & Labor
