X-ray generator: Monoblock 80 kHz high-frequency, micro-processor controlled generator
Nominal power: 15 kW: 120 kV, 125 mA
Free space within C-arm: 77 cm (30.3”)
Angulation: 90° to -25°
C-arm depth: 61 cm (24.0”)
Rotation: ± 180°, with safety stop at ± 135°
Source Image Distance: 98 cm (38.7”)
Extended angulation (optional): 90° to -45° for increased projection flexibility
Lowest lateral working position: 102 cm (40.0”)
Image intensifier: Triple mode 9″ HRC / Triple mode 12″
TV camera type: CCD, high resolution 1K²
Nominal II formats: 31, 23, and 17 cm (12”, 9”, and 7”) 23, 17, and 13 cm (9”, 7”, and 5”)
Constant beam filtration: 0.1 mm Cu 3 mm AI
Image processing: 16 bit with motion detection
Stand monitor: 12” LCD monitor on the C-arm gives visual control to the operator
Handheld remote control: Controls the main image handling functions
Touchscreen: Available for Mobile View Station
ViewForum: Multi-modality workstation
Vascular Extension: Subtracted fluoroscopy mode, Trace, View Trace, Roadmap, Remask, Smart Mask, Landmarking, real-time Pixel Shift, and CO² modes
Video in: S-video
Analog video out: 1 BNC connector left monitor
Digital video out (optional): 2 DVI connectors left and right monitor
USB storage: bmp format
Advanced DICOM/IHE package (optional): Modality Worklist Management, Modality Performed Procedure Step Storage Commit, Full compliance to the IHE Scheduled Workflow Integration profile as an Acquisition Modality Actor, Supports DICOM Structured Dose Reporting, Query/Retrieve (with the ViewForum option)
